Overview<\/h3>\n
The SRC Series Plug-in Type I\/O Modules adopt a structure combining coupler modules, power modules, and I\/O modules. The coupler connects scalable I\/O modules to the real-time industrial Ethernet system, with the backplane adopting the S-Link bus. The coupler module is responsible for fieldbus communication, thereby realizing the function of real-time data exchange between various I\/O modules and the coupler\/controller.<\/div>\n
<\/div>\n
The SRC Series Modules feature a rich variety and high real-time performance, providing guarantees for users in terms of high-speed data acquisition, system configuration optimization, on-site wiring simplification, and<\/div>\n
<\/div>\n
<\/div>\n
<\/div>\n
<\/div>\n
<\/div>\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n
Model<\/th>\n Description<\/th>\n<\/tr>\n<\/thead>\n
SRC8100<\/td>\n Profinet Bus Coupler Module<\/td>\n<\/tr>\n
SRC8200<\/td>\n EtherCAT Bus Coupler Module<\/td>\n<\/tr>\n
SRC2116<\/td>\n 16-Channel Digital Output Module, NPN Type, 24VDC, 0.5A<\/td>\n<\/tr>\n
SRC2216<\/td>\n 16-Channel Digital Output Module, PNP Type, 24VDC, 0.5A<\/td>\n<\/tr>\n
SRC1116<\/td>\n 16-Channel Digital Input Module, NPN Type, 24VDC, Filtering: 3ms<\/td>\n<\/tr>\n
SRC1216<\/td>\n 16-Channel Digital Input Module, PNP Type, 24VDC, Filtering: 3ms<\/td>\n<\/tr>\n
SRC3118<\/td>\n 8-Channel Analog Voltage Input Module<\/td>\n<\/tr>\n
SRC3138<\/td>\n 8-Channel Analog Current Input Module<\/td>\n<\/tr>\n
SRC4018<\/td>\n 8-Channel Analog Voltage Output Module<\/td>\n<\/tr>\n
SRC4038<\/td>\n 8-Channel Analog Current Output Module<\/td>\n<\/tr>\n
SRC3601<\/td>\n 1-Channel Electric Energy Acquisition Module, 690V, 5A, 5 groups of software acquisition channels<\/td>\n<\/tr>\n
SRC3602<\/td>\n 1-Channel Electric Energy Acquisition Module, 120V, 5A, 15 groups of software acquisition channels, PT\/CT Transformation Ratio<\/td>\n<\/tr>\n
SRC3603<\/td>\n 1-Channel Electric Energy Acquisition Module, 690V, 5A, 5 groups of software acquisition channels, with added frequency change rate<\/td>\n<\/tr>\n
SRC3604<\/td>\n 1-Channel Electric Energy Acquisition Module, 690V, 5A, 15 groups of software acquisition channels<\/td>\n<\/tr>\n
SRC3804<\/td>\n 4-Channel Resistance Thermometer & Thermocouple Temperature Acquisition Module<\/td>\n<\/tr>\n
SRC5001<\/td>\n 24V Single-Ended Incremental Encoder Counting Module<\/td>\n<\/tr>\n
SRC5031<\/td>\n 5V Differential Incremental Encoder Counting Module<\/td>\n<\/tr>\n
SRC5041<\/td>\n SSI Encoder Counting Module<\/td>\n<\/tr>\n
SRC5042<\/td>\n 2-Channel High-Speed Pulse Counting Module<\/td>\n<\/tr>\n
SRC6041<\/td>\n RS485\/RS422\/RS232 Gateway Module<\/td>\n<\/tr>\n
SRC6051<\/td>\n CANopen Master Gateway Module<\/td>\n<\/tr>\n<\/tbody>\n<\/table>","website":"","contact":"","seo_title":"","seo_keyword":"","seo_desc":"","share_switch":"0","share_code":"","author":"","published_time":"1761879088","add_time":"1761817406","update_time":"1787225318","corp_auth_id":"0","verify_code_auth_id":"0","editor_type":"1","file_type":"","auth_id":"[\"-1\"]","pure_content":"Overview\nThe SRC Series Plug-in Type I\/O Modules adopt a structure combining coupler modules, power modules, and I\/O modules. The coupler connects scalable I\/O modules to the real-time industrial Ethe"},{"id":"645370","string_id":"yWLufWV9","status":"1","parent_id":"193411","slug":"SRE","order":"6","name":"SRE Serise IO","type":"1","cover":"","cover_alt":"","desc":"
Product overview<\/h3>\n
The SRE series IO products use a 100M backplane bus, with a scan cycle as short as 125μs. A single coupler can be expanded to 2048DI, 2048DO, 512AI and 512AO at most, which is suitable for high-speed, high-precision, multi-detection point real-time bus control applications. The SR series supports more than 70 types of modules. In addition to traditional digital and analog input\/output modules, it also provides position acquisition modules, Ethernet\/IP master modules, MODBUS master\/slave modules, DeviceNet master\/slave modules, and stepper motor drive modules, which can easily integrate fieldbus devices including CANopen, DeviceNet, Ethernet\/IP, etc. into the EtherCAT system.<\/p>\n
<\/p>\n
<\/p>\n
\n
Product model<\/h3>\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n
Model<\/strong><\/td>\n Description<\/strong><\/td>\n<\/tr>\n
SRE8200<\/td>\n EtherCAT bus, 2 RJ45 ports, high-performance backplane bus, expandable up to 64 modules.<\/td>\n<\/tr>\n
SRE9020<\/td>\n ----<\/td>\n<\/tr>\n
SRE9001<\/td>\n Power relay module<\/td>\n<\/tr>\n
Digital input<\/td>\n<\/tr>\n
SRE1016<\/td>\n 16 channel digital input, supports PNP\/NPN input.<\/td>\n<\/tr>\n
SRE1032<\/td>\n 32 channel digital input, supports PNP\/NPN input.<\/td>\n<\/tr>\n
SRE5072<\/td>\n 2 channel digital input oversampling module.<\/td>\n<\/tr>\n
Digital output<\/td>\n<\/tr>\n
SRE2116<\/td>\n 16 channel digital output, transistor NPN, rated 0VDC (±3V)\/0.5A.<\/td>\n<\/tr>\n
SRE2216<\/td>\n 16 channel digital output, transistor PNP, rated 24VDC\/0.5A.<\/td>\n<\/tr>\n
SRE2132<\/td>\n 32 channel digital output, transistor NPN, rated 0VDC (±3V)\/0.5A, total not exceeding 10A per module.<\/td>\n<\/tr>\n
SRE2232<\/td>\n 32 channel digital output, transistor PNP, rated 24VDC\/0.5A, total not exceeding 10A per module.<\/td>\n<\/tr>\n
SRE5202<\/td>\n 2 channel digital output oversampling module.<\/td>\n<\/tr>\n
SRE5204<\/td>\n 4 channel digital output oversampling module.<\/td>\n<\/tr>\n
Digital input and output<\/td>\n<\/tr>\n
SRE1332<\/td>\n 16 channel NPN input, 16-channel transistor NPN output.<\/td>\n<\/tr>\n
SRE1432<\/td>\n 16 channel PNP input, 16-channel transistor PNP output.<\/td>\n<\/tr>\n
Analog input<\/td>\n<\/tr>\n
SRE3522<\/td>\n 2 channel analog fast acquisition module<\/td>\n<\/tr>\n
SRE3204<\/td>\n 4 channel voltage\/current input, 16-bit precision.<\/td>\n<\/tr>\n
SRE3208<\/td>\n 8 channel voltage\/current input, 16-bit precision.<\/td>\n<\/tr>\n
SRE3284<\/td>\n 4 channel thermocouple input module.<\/td>\n<\/tr>\n
SRE3274<\/td>\n 4 channel resistance thermometer input module.<\/td>\n<\/tr>\n
Analog output<\/td>\n<\/tr>\n
SRE4204<\/td>\n 4 channel voltage\/current output, ±10V or 0~20mA, 16-bit precision.<\/td>\n<\/tr>\n
SRE4208<\/td>\n 8 channel voltage\/current output, ±10V or 0~20mA, 16-bit precision.<\/td>\n<\/tr>\n
Serial port module<\/td>\n<\/tr>\n
SRE6002<\/td>\n Serial port module, with 2 RS422\/RS232\/RS485 interfaces, supports Modbus RTU and free port protocol and a maximum baud rate of 115.2Kbps.<\/td>\n<\/tr>\n
SRE6004<\/td>\n Serial port module, with 4 RS422\/RS232\/RS485 interfaces, supports Modbus RTU and free port protocol and a maximum baud rate of 115.2Kbps.<\/td>\n<\/tr>\n
Counting module<\/td>\n<\/tr>\n
SRE5012<\/td>\n 2-channel high-speed counting module, with 2 sets of A, B, and C counting inputs and single-ended (max 200KHZ at rated 24V, supporting PNP\/NPN input) or differential (max 4MHZ at 5V), supports standard counting functions.<\/td>\n<\/tr>\n
SRE5034<\/td>\n 4-channel high-speed counting module, with 4 sets of A, B, and C counting inputs, differential (max 4MHz at 5V), supports standard counting functions.<\/td>\n<\/tr>\n
SRE5042<\/td>\n SSI decoding module, with 2 sets of synchronous serial (D+, D-, CL+, CL-) inputs, and a maximum communication rate of 1MHz, supports multi-turn or single-turn SSI encoder input.<\/td>\n<\/tr>\n
SRE5234<\/td>\n High-speed pulse output module, with 4-axis PTO output, NPN single-ended output up to 400KHz (at 5V), and differential output up to 1MHz.<\/td>\n<\/tr>\n
Protocol Gateway Conversion Module<\/td>\n<\/tr>\n
SRE6051<\/td>\n CAN Protocol Conversion Module, with 1 CAN interface, supports CANopen protocol and a maximum baud rate of 1Mbit\/s<\/td>\n<\/tr>\n
SRE6051F<\/td>\n CAN Protocol Conversion Module, with 1 CAN interface, supports CAN 2.0A\/B protocol and maximum baud rate of 1Mbit\/s<\/td>\n<\/tr>\n
SRE6061<\/td>\n PROFINET Protocol Conversion Module, PROFINET specification: V2.3, supports 128 slave stations<\/td>\n<\/tr>\n
SRE6081<\/td>\n DeviceNet Protocol Conversion Module, supports a maximum baud rate of 500kbit\/s<\/td>\n<\/tr>\n
SRE6091<\/td>\n Profibus DP protocol conversion module, supports baud rates of 9.6Kbps, 19.2Kbps, 31.25Kbps, 45.45Kbps, 93.75Kbps, 187.5Kbps, 500Kbps, 1500Kbps, 300Kbps, 6000Kbps, and 12000Kbps.<\/td>\n<\/tr>\n<\/tbody>\n<\/table>\n
<\/p>","website":"","contact":"","seo_title":"","seo_keyword":"","seo_desc":"","share_switch":"0","share_code":"","author":"","published_time":"1762395377","add_time":"1761876827","update_time":"1787225318","corp_auth_id":"0","verify_code_auth_id":"0","editor_type":"1","file_type":"","auth_id":"[\"-1\"]","pure_content":"Product overview\nThe SRE series IO products use a 100M backplane bus, with a scan cycle as short as 125\u03bcs. A single coupler can be expanded to 2048DI, 2048DO, 512AI and 512AO at most, which is suitabl"},{"id":"645378","string_id":"eIBH1W0z","status":"1","parent_id":"193411","slug":"SRR","order":"5","name":"SRR Series IO","type":"1","cover":"","cover_alt":"","desc":"
Overview<\/h3>\n
The SRR Series Plug-in Type I\/O Modules adopt a structure combining couplers and I\/O modules. The coupler connects scalable I\/O modules to the real-time industrial Ethernet system, with the backplane adopting the S-Link Bus. The coupler module is responsible for fieldbus communication, thereby realizing the function of real-time data exchange between various I\/O modules and the coupler\/controller.<\/div>\n
<\/div>\n
The SRR Series Modules feature a rich variety and high real-time performance, providing guarantees for users in terms of high-speed data acquisition, system configuration optimization, on-site wiring simplification, and system reliability improvement.<\/div>\n
<\/h3>\n
\n
Product Models<\/h3>\n
\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n
Model<\/th>\n Description<\/th>\n<\/tr>\n<\/thead>\n
SRR8200<\/td>\n EtherCAT Bus Coupler Module<\/td>\n<\/tr>\n
SRR8300<\/td>\n Profinet Bus Coupler Module<\/td>\n<\/tr>\n
SRR1008<\/td>\n 8-Channel Digital Input Module, Input NPN\/PNP Compatible, Default Input Filtering: 3ms<\/td>\n<\/tr>\n
SRR1016<\/td>\n 16-Channel Digital Input Module, Input NPN\/PNP Compatible, Default Input Filtering: 3ms<\/td>\n<\/tr>\n
SRR1032<\/td>\n 32-Channel Digital Input Module, Input NPN\/PNP Compatible, Default Input Filtering: 3ms<\/td>\n<\/tr>\n
SRR1316<\/td>\n 8-Channel Digital Input + 8-Channel Digital Output Module, Input NPN\/PNP Compatible, Default Input Filtering: 3ms, Output NPN Type<\/td>\n<\/tr>\n
SRR1332<\/td>\n 16-Channel Digital Input + 16-Channel Digital Output Module, Input NPN\/PNP Compatible, Default Input Filtering: 3ms, Output NPN Type<\/td>\n<\/tr>\n
SRR1416<\/td>\n 8-Channel Digital Input + 8-Channel Digital Output Module, Input NPN\/PNP Compatible, Default Input Filtering: 3ms, Output PNP Type<\/td>\n<\/tr>\n
SRR1432<\/td>\n 16-Channel Digital Input + 16-Channel Digital Output Module, Input NPN\/PNP Compatible, Default Input Filtering: 3ms, Output PNP Type<\/td>\n<\/tr>\n
SRR2108<\/td>\n 8-Channel Digital Output Module, Output NPN Type<\/td>\n<\/tr>\n
SRR2116<\/td>\n 16-Channel Digital Output Module, Output NPN Type<\/td>\n<\/tr>\n
SRR2132<\/td>\n 32-Channel Digital Output Module, Output NPN Type<\/td>\n<\/tr>\n
SRR2208<\/td>\n 8-Channel Digital Output Module, Output PNP Type<\/td>\n<\/tr>\n
SRR2216<\/td>\n 16-Channel Digital Output Module, Output PNP Type<\/td>\n<\/tr>\n
SRR2232<\/td>\n 32-Channel Digital Output Module, Output PNP Type<\/td>\n<\/tr>\n
SRR3214<\/td>\n 4-Channel Analog Voltage Input Module, Single-Ended Signal, Adjustable Measurement Range: Disable, -10V~+10V, 0V~10V, -5V~+5V, 0V~5V, 1V~5V<\/td>\n<\/tr>\n
SRR3218<\/td>\n 8-Channel Analog Voltage Input Module, Single-Ended Signal, Adjustable Measurement Range: Disable, -10V~+10V, 0V~10V, -5V~+5V, 0V~5V, 1V~5V<\/td>\n<\/tr>\n
SRR3234<\/td>\n 4-Channel Analog Current Input Module, Single-Ended Signal, Adjustable Measurement Range: Disable, 4mA~20mA, 0mA~20mA<\/td>\n<\/tr>\n
SRR3238<\/td>\n 8-Channel Analog Current Input Module, Single-Ended Signal, Adjustable Measurement Range: Disable, 4mA~20mA, 0mA~20mA<\/td>\n<\/tr>\n
SRR3258<\/td>\n 8-Channel Analog Voltage Input Module, Differential Signal, Adjustable Measurement Range: Disable, -10V~+10V, 0V~10V, -5V~+5V, 0V~5V, 1V~5V<\/td>\n<\/tr>\n
SRR3268<\/td>\n 8-Channel Analog Current Input Module, Differential Signal, Adjustable Measurement Range: Disable, 4mA~20mA, 0mA~20mA, -20mA~+20mA<\/td>\n<\/tr>\n
SRR3294<\/td>\n 4-Channel Temperature Measurement Module<\/td>\n<\/tr>\n
SRR4014<\/td>\n 4-Channel Analog Voltage Output Module, Single-Ended Signal, Adjustable Measurement Range: Disable, -10V~+10V, 0V~10V, -5V~+5V, 0V~5V, 1V~5V<\/td>\n<\/tr>\n
SRR4018<\/td>\n 8-Channel Analog Voltage Output Module, Single-Ended Signal, Adjustable Measurement Range: Disable, -10V~+10V, 0V~10V, -5V~+5V, 0V~5V, 1V~5V<\/td>\n<\/tr>\n
SRR4034<\/td>\n 4-Channel Analog Current Output Module, Single-Ended Signal, Adjustable Measurement Range: Disable, 4mA~20mA, 0mA~20mA<\/td>\n<\/tr>\n
SRR4038<\/td>\n 8-Channel Analog Current Output Module, Single-Ended Signal, Adjustable Measurement Range: Disable, 4mA~20mA, 0mA~20mA<\/td>\n<\/tr>\n
SRR5001<\/td>\n 1-Channel High-Speed Counting Module<\/td>\n<\/tr>\n
SRR5031<\/td>\n 1-Channel High-Speed Counting Module<\/td>\n<\/tr>\n
SRR5041<\/td>\n 1-Channel High-Speed Counting Module (SSI)<\/td>\n<\/tr>\n
SRR6001<\/td>\n 1-Channel Serial Communication Module<\/td>\n<\/tr>\n
SRR9001<\/td>\n Expansion Power Module<\/td>\n<\/tr>\n
SRR9010<\/td>\n Terminal Cover Plate<\/td>\n<\/tr>\n<\/tbody>\n<\/table>\n
<\/div>","website":"","contact":"","seo_title":"","seo_keyword":"","seo_desc":"","share_switch":"0","share_code":"","author":"","published_time":"1762395379","add_time":"1761876979","update_time":"1787225318","corp_auth_id":"0","verify_code_auth_id":"0","editor_type":"1","file_type":"","auth_id":"[\"-1\"]","pure_content":"Overview\nThe SRR Series Plug-in Type I\/O Modules adopt a structure combining couplers and I\/O modules. The coupler connects scalable I\/O modules to the real-time industrial Ethernet system, with the b"},{"id":"645394","string_id":"gvCiboXH","status":"1","parent_id":"193411","slug":"SRT","order":"4","name":"SRT Series IO","type":"1","cover":"","cover_alt":"","desc":"
Overview<\/h3>\n
The SRT series I\/O modules are high-performance plug-in remote I\/O solutions launched by Sinsegye, designed specifically for industrial automation scenarios. This series of modules adopts a modular architecture, supports flexible expansion, and has the characteristics of high real-time performance, strong compatibility, and easy maintenance.<\/p>\n
<\/p>","website":"","contact":"","seo_title":"","seo_keyword":"","seo_desc":"","share_switch":"0","share_code":"","author":"","published_time":"1762395384","add_time":"1761877007","update_time":"1787225318","corp_auth_id":"0","verify_code_auth_id":"0","editor_type":"1","file_type":"","auth_id":"[\"-1\"]","pure_content":"Overview\nThe SRT series I\/O modules are high-performance plug-in remote I\/O solutions launched by Sinsegye, designed specifically for industrial automation scenarios. This series of modules adopts a m"},{"id":"925437","string_id":"NKb3rNpv","status":"1","parent_id":"193411","slug":"NKb3rNpv","order":"3","name":"SRI Series IO","type":"1","cover":"","cover_alt":"","desc":"","website":"","contact":"","seo_title":"","seo_keyword":"","seo_desc":"","share_switch":"0","share_code":"","author":"","published_time":"1787227559","add_time":"1787225315","update_time":"1787227559","corp_auth_id":"0","verify_code_auth_id":"0","editor_type":"1","file_type":"","auth_id":"[\"-1\"]","pure_content":""},{"id":"209817","string_id":"ibhsSKSu","status":"1","parent_id":"193411","slug":"SC","order":"2","name":"SC Series","type":"1","cover":"","cover_alt":"","desc":"
The SC series I\/O products are engineered to excel in environments where high-speed, high-precision real-time bus and control systems are critical. With their compact design, these products are ideal for applications that demand high-volume data processing, making them suitable for a broad spectrum of industries, including automation, robotics, and manufacturing. Their ability to handle intensive workloads while maintaining top-tier performance makes them an essential component in modern control systems.<\/p>\n
One of the key advantages of the SC series is the variety of I\/O types available. Whether the application requires digital inputs, outputs, analog signals, or specialized interfaces, the SC series provides a comprehensive range of options. This diversity enables users to select the right configuration that best fits their specific needs, enhancing the flexibility and scalability of their systems. By offering a wide selection of products, the SC series ensures that users can find the perfect match for their application requirements, minimizing the need for costly custom solutions.<\/p>\n
In addition to the range of types, the SC series is renowned for its plug-and-play capability. This feature significantly reduces the time and complexity associated with installation. Users can quickly integrate the products into existing systems without the need for intricate setup procedures or additional configuration software. The ease of integration not only accelerates deployment but also minimizes the likelihood of errors during installation, ensuring a smooth and reliable start to any project.<\/p>\n
Real-time performance is another area where the SC series truly shines. Designed for ultra-fast data exchange, these I\/O products provide rapid response times, making them an excellent choice for applications where latency is a critical factor. Whether used in real-time control loops or high-speed data collection, the SC series ensures that actions are executed almost instantaneously, reducing delays and improving the overall efficiency of the system.<\/p>\n
Moreover, the SC series is built with cost-effectiveness in mind. While it delivers high performance and advanced features, the products are designed to be budget-friendly, offering an excellent balance between quality and affordability. By reducing the overall cost of hardware deployment without compromising on performance, the SC series enables businesses to achieve significant savings in their system setups while still maintaining industry-leading capabilities.<\/p>\n
Finally, the compact size of the SC series products makes them especially suitable for environments where space is at a premium. Their small footprint allows them to be integrated into tight spaces or existing setups without the need for substantial changes to infrastructure. This compactness, paired with their high functionality, ensures that users can maximize the available space while benefiting from cutting-edge I\/O technology.<\/p>\n
